Product Application
GYTS outdoor loose tube layer-stranded type optical cable(steel strip longitudinal wrap) is applied to remote and interoffice communication,laying mode: pipe laying and overhead laying.
Features
1) Small transmission loss and low chromatic dispersion.
2) Excellent mechanical properties and has good capability of resisting bending.
3) Excellent mechanical properties and envronmental performances due to reasonable design and precision control of the redundant length and the cabling method of the optical fiber in the loose tube.
4) The loose tube filled with gel and can make ensures the fiber transmission stability for long time.
5) The parts outside the reinforcing member and in the cable conductor are full of water-blocking cable paste; therefore the damp-proofand water-blocking effects of the optical cable can make sure.
6) 9/125 single-mode fber,50/125 multimode fiber.62.5/125 multimode fiber and OM1.OM2.OM3 multimode fibers can be chosen.
The Order Information
1) Tight sleeve material type: V-PVC H-LSZH Y-Hytrel N-Nylon E-ETFE
2) FiberType: B1.3 B6a1 B6a2 B6b3 A1a A1b BIOM2 BIOM2+ BIOM3 BIOM4 BIOM5
3) Jacket Material: Polyvinyl chloride(PVC), Low smoke zero halogen(LSZH),
Therm oplatic polyurethane(TPU). or other contracted material
4) Jacket color: (Including color of fiber) Meets the requirements of relevant standards, or other contracted color
5) Cable Dimension: The nominal cable dimension or other contracted dimension
6) Delivery Length: 1KM or 2KM or other contracted length
7) Other Requirements: Other contracted special reques
